IMP::container::QuadsConstraint Class Reference

---

Detailed Description

Apply a QuadFunction to a QuadContainer to maintain an invariant.

The score state is passed up to two QuadModifiers, one to apply before evaluation and the other after. The one after should take a DerivativeAccumulator as its last argument for QuadModifier::apply() and will only be called if the score was computed with derivatives.

An example showing a how to use such a score state to maintain a cover of the atoms of a protein by a sphere per residue.

import IMP
import IMP.core
import IMP.atom
import IMP.atom
import IMP.helper

m= IMP.Model()
prot= IMP.atom.read_pdb(IMP.core.get_example_path('example_protein.pdb'), m)
res= IMP.atom.get_by_type(prot, IMP.atom.RESIDUE_TYPE)
for p in res:
    IMP.core.XYZR.setup_particle(p.get_particle())
mtr=IMP.atom.Hierarchy.get_traits()
pr= IMP.core.ChildrenRefiner(mtr)
for r in res:
    IMP.core.Cover.setup_particle(r.get_particle(), pr)
m.evaluate(False)

See also:

QuadConstraint

Inheritance diagram for IMP::container::QuadsConstraint:

[legend]

Public Member Functions
virtual std::string	get_type_name () const
virtual ::IMP::VersionInfo	get_version_info () const
	QuadsConstraint (QuadContainer *c, QuadModifier *before, QuadModifier *after, std::string name="QuadConstraint %1%")
void	set_after_evaluate_modifier (QuadModifier *f)
	Apply this modifier to all the elements after an evaluate.
void	set_before_evaluate_modifier (QuadModifier *f)
	Apply this modifier to all the elements before an evaluate.
Protected Member Functions
void	do_update_attributes ()
void	do_update_derivatives (DerivativeAccumulator *da)
virtual ContainersTemp	get_input_containers () const
virtual ParticlesTemp	get_input_particles () const
virtual ParticlesList	get_interacting_particles () const
virtual ContainersTemp	get_output_containers () const
virtual ParticlesTemp	get_output_particles () const
Friends
template<class T >
void	IMP::internal::unref (T *)

---

Constructor & Destructor Documentation

IMP::container::QuadsConstraint::QuadsConstraint	(	QuadContainer *	c,
		QuadModifier *	before,
		QuadModifier *	after,
		std::string	name = "QuadConstraint %1%"
	)

Parameters:

[in]	c	The Container to hold the elements to process
[in]	before	The QuadModifier to apply to all elements before evaluate.
[in]	after	The QuadModifier to apply to all elements after evaluate.
[in]	name	The object name

---

The documentation for this class was generated from the following files:

• QuadsConstraint.h
• container/__init__.py
